MORI WMF EXTRACT

Weatherproof Subfloor Ventilation Extract Fan

  • Creates a controlled airflow path across the subfloor void, drawing new air in through perimeter openings and removing moisture-laden air.
  • Low energy fan/motor assembly with typical electrical running costs under £9 per year for continuous operation.
  • Adjustable low running and Boost speeds for perfect ventilation in a wide variety of installations.
  • Improves airflow beneath the floors of a building to prevent moisture buildup, reduce humidity, and promote a healthier indoor environment.
Select Available Next Day

SKU: ET-050001/A

42 in stock

Quantity

Got a question about this product?

Email us or call us on +44 (0) 1384 275800

Compatible Accessories

Product Overview

The MORI WMF EXTRACT is a weatherproof fan unit for use when an easily accessed, externally mountable, continuously running ventilation fan is required e.g. to provide subfloor ventilation.

Many subfloor spaces have insufficient natural ventilation with the only option to provide some form of mechanical ventilation to the space. The MORI WMF was specifically designed for such applications.

The combination of wide airflows and various control modes provides the sub-floor ventilation system designer with more choice and flexibility.

Features and Benefits

  • Unique weatherproof design allowing the fan to be mounted outside making installation and maintenance easier than with subfloor mounted fans.
  • Low energy fan/motor assembly with typical electrical running cost under £9 per year for continuous operation.
  • Designed to provide: Continuous fan operation at an adjustable trickle speed, Adjustable Boost speed activated by an external switch (where fitted), Extract Ventilation.
  • Can be used in conjunction with the Supply model to provide a complete subfloor ventilation solution (recommended).

Operation

The integral controls provided as standard allow for the fan to be set at the installation stage to operate at a trickle speed/airflow. When connected to a boost switch, on closure of the boost switch, the fan will run at a determined speed set internally within the fan at set up; when the boost switch is open the fan will revert to trickle speed.
